CDA1.0
Features for 2018
Lightweight triple butted Mu9 Alloy Frame
Thru frame cable routing, fully enclosed cables for minimum mud intrusion
Bridge-less chainstays for reduced mud clogging
Lower Centre of Gravity for improved handling and stability
Full carbon monocoque fork
15mm thru axle front and 12mm thru axle rear for maximum stiffness and responsiveness
Post mount front caliper and flat mount rear caliper for optimum balance of stiffness, weight and packaging
Designed for 140mm disks front and rear.
CDA1.0 Hydro Disc
FRAME – WORX HYDROFORMED PROFILED VANADIUM ENRICHED ALUMINIUM MU9 TRIPLE BUTTED
FORK – FULL MONOCOQUE CARBON FORX AND TAPERED STEERER TUBE
HEADSET – FSA ORBIT C40
REAR MECH – SRAM FORCE 1
DERAILLEUR HANGER – WORX 7075
BRAKE/SHIFT LEVERS – SRAM FORCE 1
BRAKES – SRAM FORCE HYDRO 140mm disc
CASSETTE – SRAM PG1130 11-32
WHEELSET – MICHE GRAF
TYRES – CONTINENTAL CX
CRANKS – WORX 160mm to 175mm
CHAINRINGS – SRAM X-Sync 40T
BOTTOM BRACKET – SRAM BB30A
COCKPIT – WORX HANDLEBAR 360mm to 440mm
HANDLEBAR TAPE – CUSTOM
SADDLE – dependent on availability
PEDALS – N/A
FRAME SIZES – 49 (XS) ,51 (S) ,53 (M) ,56 (L) ,58 (XL)
Images show optional carbon wheelset
Specs may vary, depending on availability
CDA1.0 Cable Disc
FRAME – WORX HYDROFORMED PROFILED VANADIUM ENRICHED ALUMINIUM MU9 TRIPLE BUTTED
FORK – FULL MONOCOQUE CARBON FORX AND TAPERED STEERER TUBE
HEADSET – FSA ORBIT C40
REAR MECH – SRAM RIVAL 1
DERAILLEUR HANGER – WORX 7075
BRAKE/SHIFT LEVERS – SRAM RIVAL 1
BRAKES – SPYRE SLC 140mm disc
CASSETTE – SRAM PG1130 11-32
WHEELSET – MICHE GRAF
TYRES – CONTINENTAL CX
CRANKS – WORX 160mm to 175mm
CHAINRINGS – SRAM X-Sync 40T
BOTTOM BRACKET – SRAM BB30A
COCKPIT – WORX HANDLEBAR 360mm to 440mm
HANDLEBAR TAPE – CUSTOM
SADDLE – dependent on availability
PEDALS – N/A
FRAME SIZES – 49 (XS) ,51 (S) ,53 (M) ,56 (L) ,58 (XL)
Images show optional carbon wheelset
Specs may vary, depending on availability
